Quick answer: A fuel tanker semi-trailer commonly carries 30,000 to 60,000 litres (about 7,900 to 15,900 US gallons), depending on axle count, fuel density and the weight limits of the roads it runs on. Smaller rigid tank trucks usually carry well under 20,000 litres. CHENLU fuel tanker trailers are built with 40,000 to 50,000 litres of total volume, split into a single compartment or 2 to 7 compartments.
Fuel tanker capacity cannot be chosen from volume alone. The same tank holds a different weight of petrol than of diesel, and the loaded weight, not the litres, is what road law limits. This guide gives you the typical capacity ranges, the conversions buyers ask for, and a step-by-step way to size a tanker for your fuel and route.
Capacity depends mainly on the type of vehicle and the number of axles:
| Vehicle type | Typical total capacity | Remarques |
|---|---|---|
| Rigid tank truck (fuel bowser) | Commonly 5,000-20,000 L | Local delivery to filling stations, farms and sites |
| 2- or 3-axle fuel tanker semi-trailer | Commonly 30,000-50,000 L | Most common for long-distance fuel haulage |
| 4-axle or larger fuel tanker semi-trailer | Up to about 60,000 L where road law allows | Higher volume needs more axles to stay within axle-load limits |
These are general industry ranges, not legal limits. Your permitted load depends on the destination country’s gross-weight and axle-load rules.
In the United States, a road tanker for gasoline is often cited at around 9,000 US gallons (about 34,000 litres). In many export markets, 40,000 to 50,000 litre tri-axle tankers are common.
Because petrol is lighter than diesel, the same tank volume produces a different load weight. The table uses typical densities of about 0.74 kg/L for petrol (gasoline) and 0.84 kg/L for diesel; actual density varies with fuel grade and temperature.
| Tank volume (litres) | US gallons | Imperial gallons | Petrol weight (approx.) | Diesel weight (approx.) |
|---|---|---|---|---|
| 30,000 L | 7,925 | 6,599 | 22.2 t | 25.2 t |
| 35,000 L | 9,246 | 7,699 | 25.9 t | 29.4 t |
| 40,000 L | 10,567 | 8,799 | 29.6 t | 33.6 t |
| 45,000 L | 11,888 | 9,899 | 33.3 t | 37.8 t |
| 50,000 L | 13,209 | 10,998 | 37.0 t | 42.0 t |
| 60,000 L | 15,850 | 13,198 | 44.4 t | 50.4 t |
Conversions: 1 US gallon = 3.785 L; 1 imperial gallon = 4.546 L; 1 m³ = 1,000 L. Liquid weight = volume × density. Tonnes shown are cargo weight only, without the trailer and tractor.
This is why a 50,000 litre tank that is legal for petrol can be overweight with diesel on the same route: the diesel load is about 5 tonnes heavier.
The first calculation is the mass of the liquid. Multiply the planned volume by the operating density, then compare that mass with the permitted payload after deducting the tractor and trailer tare weights. The same tank volume creates a different axle load and gross-combination mass when the product changes.
Do not treat the tank’s geometric volume as its guaranteed usable volume. Outage (the space left for thermal expansion), loading procedure and compartment rules can reduce the quantity carried. The applicable authority and the cargo-handling procedure determine the final fill limit.
Worked example (illustrative): if your route allows 36 tonnes of liquid payload after tare weights, that equals about 48,600 litres of petrol (36,000 kg ÷ 0.74) but only about 42,900 litres of diesel (36,000 kg ÷ 0.84). A tank sized for the diesel case, then used for petrol, simply runs partly empty; a tank sized for petrol and filled with diesel can be overweight.
| Facteur | Effet de capacité | Avis des acheteurs requis |
|---|---|---|
| Densité du liquide | Une densité plus élevée permet d'atteindre la limite de masse avec un volume moindre | Densité des produits et densité d'exploitation |
| Matériau du réservoir | Material and structure change tare weight and available payload | Acier au carbone, aluminium ou tout autre matériau compatible |
| Plan des compartiments | Les cloisons, les canalisations et les vannes alourdissent l'ensemble, mais permettent des alimentations séparées | Nombre de produits, de doses et ordre de déchargement |
| Disposition des essieux | Le volume total peut tout de même entraîner une surcharge sur un groupe d'essieux | Configuration du tracteur, nombre d'essieux et limites légales relatives aux essieux |
| Pompe et accessoires | Equipment adds tare weight and takes space | Exigences relatives au chargement, au déchargement et au contrôle des vapeurs |
| Itinéraire et température | Road restrictions and expansion allowance can reduce the load | Pays, état des routes et plage de températures |
Length, width and height set the physical limit on tank volume. For reference, CHENLU fuel tanker semi-trailers rated 40,000-50,000 litres measure 10,200-12,000 mm long, 2,500 mm wide and 3,800-3,990 mm high, with a tare weight of about 7,500-15,000 kg depending on configuration. A longer custom build delivered to a customer in Congo carries 50,000 litres in five compartments at 16,500 × 2,500 × 3,850 mm. Always check the destination’s maximum length and height before choosing a larger tank. For full length, width and height ranges by tanker type, see our Guide des dimensions des semi-remorques-citernes.
| Paramètre | CHENLU specification |
|---|---|
| Volume total | 40,000-50,000 L |
| Compartiments | Single, or 2 to 7; each hydrostatically tested to 5 psi (35 kPa) |
| Corps de la citerne / fonds | Acier au carbone Q235 de 5 mm ou 6 mm |
| Essieux | 2 or 3 axles (13T/16T) on the standard chassis; a 4-axle petrol tanker model is also available |
| Valves | 3″ Euro-standard ball valve; 2 × 4″ bottom valves with pneumatic control |
| Options | Insulation, oil vapor recovery system and pump unit (on the 40,000 L multi-compartment tanker) |
See the full range and specifications on our tanker trailer page, or the individual models: Semi-remorque-citerne à essence, Semi-remorque-citerne à carburant à 3 essieux et 40000 Litre Tanker Trailer.
A single-compartment tank simplifies the internal arrangement and suits one product delivered as one load. Multiple compartments let you carry different fuels, such as petrol and diesel, or serve several delivery points on one trip, but bulkheads, valves and pipework add tare weight and operating steps. For example, a 45,000 litre tank might be divided into five compartments of 9,000 litres each, so each filling station receives a measured drop. Partial loading needs careful planning, because liquid movement and uneven compartment use affect axle loads and stability.
Le Forum mondial de la CEE-ONU pour l'harmonisation des réglementations relatives aux véhicules maintains international vehicle regulations covering braking, lighting, tires and coupling devices. The exact vehicle and dangerous-goods rules depend on the product, destination and approval route. CHENLU configures tankers to the regulations of your destination country, confirmed at inquiry; a general compliance statement cannot replace order-specific documentation.
A fuel tanker semi-trailer commonly holds 30,000-60,000 litres, and a rigid tank truck usually holds under 20,000 litres. CHENLU fuel tanker trailers hold 40,000-50,000 litres. The right size for your order depends on fuel density, tare weight and the axle-load limits of your route.
Petrol tankers use the same tank sizes as diesel tankers, commonly 30,000-60,000 litres on a semi-trailer. Because petrol is lighter (about 0.74 kg/L), a 40,000 litre petrol load weighs about 29.6 tonnes, compared with about 33.6 tonnes for diesel.
A semi-trailer fuel tanker of 30,000-60,000 litres holds about 7,900-15,900 US gallons. A 40,000 litre tank is about 10,600 US gallons; a 50,000 litre tank is about 13,200 US gallons.
Add the cargo weight to the tare weights. A 45,000 litre diesel load weighs about 37.8 tonnes; with a trailer tare of 7.5-15 tonnes and the tractor, the combination must still be within your route’s gross and axle limits.
Base it on the number of products, delivery points, loading sequence and cleaning needs. CHENLU tankers are available as single-compartment or with 2 to 7 compartments.
No. Payload mass, axle distribution, expansion allowance, temperature, route limits and compartment rules can restrict the usable load below the geometric tank volume.
Provide the fuel and its density, target volume, compartment plan, loading and discharge method, tractor configuration, destination country, route conditions and required accessories. Pricing is factory-direct and confirmed on inquiry.
Send us the fuel type, target volume, compartment plan and destination country through the Page de contact de CHENLU, and our engineers will check the proposed capacity against your route limits. You can also browse our fuel, aluminum and bulk cement tanker trailers.
